Pro Mini 168 Mini ATMEGA168 3.3V/8MHz

1.14 Digital input / output ports RX, TX D13, D2 ~~ of,
2 or 8 analog input port A0 to A7
3. The TTL level serial transceiver port RX / TX
4.6 PWM ports, D3,, D5 , D6, D9, D10, D11
5. Using Atmel Atmega168P microcontroller
6.supports serial download
please be informed:
this is ATmega168 Chip, 3.3v 8MHz pro mini
You can use it as below:

aeProduct.getSubject()

Harga RP. 30.000,-

CP 2102 Serial Converter USB 2.0 To TTL UART 6PIN Module

Specifications:
Built-in USB to RS232 Transfer chip.
Designed to be used for USB to TTL electronic projects.
TTL interface output, easy to connect to your MCU.
Status LED.
Dual 3.3V and 5V Power output, work with 3.3v and 5v target device.
Compact design. V1.0

Harga Rp. 45.000,-

USBASP USBISP AVR Programmer

5V/3.3V 1pcs Great quality Shell New USBASP USBISP AVR Programmer USB ATMEGA8 ATMEGA128 Support Win7 64K

This programmer is based on Thomas Fischl's USBasp design and connects to your computer's USB port. Not only is it quite compact, but the design is really elegent. The USB interface is achieved by using an atmega processor and the rest is done in firmware. For those interested, the firmware source code can be downloaded from the USBasp we b site.

Some of the features include:
Support for AVRDude from version 5.2 onwards
Allows you to to read or write the microcontroller EEPROM, firmware, fuse bits and lock bits
Support for Linux, Mac OS X and Windows (will work on vista)
5 KB/sec maximum write speed
Software controlled SCK option to support targets with low clock speed (< 1.5MHz)
10 pin ISP interface
These programmers are a perfect companion to the Protostack 28 pin AVR Development Board or the Protostack ATMEGA8 Development Kit.

Supported microcontrollers include:
Mega Series
ATmega8 ATmega48 ATmega88 ATmega168 ATmega328
ATmega103 ATmega128 ATmega1280 ATmega1281 ATmega16
ATmega161 ATmega162 ATmega163 ATmega164 ATmega169
ATmega2560 ATmega2561 ATmega32 ATmega324 ATmega329
ATmega3290 ATmega64 ATmega640 ATmega644 ATmega649
ATmega6490 ATmega8515 ATmega8535
Tiny Series
ATtiny12 ATtiny13 ATtiny15 ATtiny25 ATtiny26
ATtiny45 ATtiny85 ATtiny2313
Classic Series
AT90S1200 AT90S2313 AT90S2333 AT90S2343 AT90S4414
AT90S4433 AT90S4434 AT90S8515
